SH300 Ventilator

technical parameter:

Type: Pneumatic electric control.

Display screen: 10.4-inch touch LCD screen

Battery: Lithium battery, can supply power for more than 2 hours.

Breathing modes: VCV, VCV + Sigh, PCV, PRVC, SIMV + VCV, SIMV + PCV, SIMV + PRVC, SPONT (CPAP / PSV), BIPAP, APRV

Graphic display: Waveform: pressure-time, flow-time, volume-time Ring

diagram: pressure-volume, flow-volume Safety pressure of pneumatic

system: ≤125cmH2O.

Optional air compressor

Main setting parameters

Tidal volume: Range: 20 ～ 2500 mL;

Inspiratory time: Range: 0.1 ～ 12 s;

Breath-holding time: Range: 0-50% (relative to inspiratory time);

Pressure trigger: Range: (PEEP-20cmH2O) ~ PEEP 0 cmH2O;

Flow rate trigger: Range: 1 ～ 20 L / min;

PEEP / CPAP: Range: 0 ～ 50 cmH2O;

Pressure support: Range: 0 ～ 70 cmH2O;

Pressure control: Range: 5 ～ 70 cmH2O;

Oxygen concentration: Range: 21 ～ 100%;

High pressure level: Range: 0 ～ 70 cmH2O;

Low pressure level: Range: 0 ～ 70 cmH2O;

Pure oxygen ventilation: Pure oxygen ventilation for 2min.

Exhalation hold: When you press and hold this button, when the ventilator turns to exhalation state, close the inspiratory exhalation valve until the button is released or the longest does not exceed 15s.

Inhalation hold: When you press and hold this button, the ventilator will switch to the breath-holding section after completing this inhalation until the button is released or the longest time does not exceed 15s.

Manual inhalation: When you press and hold this button in the exhalation phase, the ventilator automatically triggers an inhalation.

Freeze: After pressing this key, the waveform stops refreshing, and press again to activate.

Atomization: The time can be adjusted from 0 to 60 minutes.

Keyboard lock: Lock the keyboard to prevent misuse.

Main monitoring parameters

Parameter Description

Inspiratory tidal volume: Range: 0 ～ 4000 mL;

Expiratory tidal volume: Range: 0 ～ 4000 mL;

Min ventilation: Range: 0 ～ 40 L / min;

Autonomous minute ventilation: Range: 0 ～ 40L / min;

Spontaneous breathing frequency: Range: 0 ～ 40 bpm;

Total respiratory rate: Range: 0 ～ 100 bpm;

Peak airway pressure: Range: 0 ～ 80 cmH2O;

Average airway pressure: Range: 0 ～ 80 cmH2O;

Inspiratory platform pressure: Range: 0 ～ 80 cmH2O;

Minimum airway pressure: Range: 0 ～ 80 cmH2O;

Inhaled oxygen concentration: Range: 18% ～ 100%;

Compliance: Range: 0 ～ 150mL / cmH2O;

Airway resistance: Range: 0 ～ 50 cmH2O / (L / S);

Positive end expiratory pressure: Range: 0 ～ 80 cmH2O;

Breathing ratio monitoring: 1: 10 ～ 10: 1;

RSBI (Shallow Fast Breathing Index);

Autopeep (endogenous PEEP);
